High Quality Blister Processing Line (AZ-05)

Customization:	Available
After-sales Service:	Onsite Instalation
Warranty:	24 Months

i

Basic Specifications

Model NO.

AZ-05

Automatic Grade

Automatic

Driven Type

Electric

Forming Species

Premade Cup

Material Type

Bulk Solid, Customized

Packaging Material

Plastic

Capacity

100-1000kg/H

Net Weight

500 Kgs

Material

S.S (Stainless Steel)

Specification

CE, ISO

★

Blister Packing Machine Overview

The AZ-05 is a high-efficiency blister processing line designed for turnkey projects. It features advanced PLC control and customized design options to meet various industrial packaging needs.

High Quality Blister Processing Line (AZ-05)

Key Specifications

Semi-automatic or fully automatic operation modes.
Adopts top brand PLC controller with multilingual touch screen (Chinese/English).
Frequency inverter for speed control and servo traction for adjustable blister length.
High efficiency with CE, ISO, and SGS certifications.

⚙

Industrial Applications

This equipment is suitable for paper-plastic packaging across multiple industries:

Industries: Hardware, Medical Equipment, Toys, Batteries, Electronics, Auto Parts, Cosmetics, and Kitchenware.

Sample Products: Syringes, flashlights, spark plugs, toothbrushes, lipsticks, facial masks, shavers, and pharmaceutical blisters.

Automatic carton opening and product insertion.
Embossing print for batch numbers (up to 3 rows).
Switchover between manual and automatic operation.
Automatic inspection system with safety shut-off for non-conforming products.

➔

Production Flow Chart

PVC Roll ➔ PVC Pre-heating ➔ Blister Forming ➔ Servo Traction ➔ Blister Cutting ➔ PVC Edge Material Collection ➔ Picking Up Blister Tray into Railway Mold ➔ Manual/Automatic Feeding ➔ Automatic Feeding Paper Card ➔ Tray Paper Heat-sealing ➔ Output

📋

Technical Parameters & Models

Model	JY-001	JY-002	JY-003
Punching frequency	15-35 times/min	AL/PVC 15-45, AL/AL 15-35	AL/PVC 20-60, Al/AL 15-30
Max production capacity	-	ALU/PVC 72k-236k pcs/h	AL/PVC 140k Grains/h
Adjustable scope of Travel	40-120mm	30-120mm	30-140mm
Max forming depth	25mm	25mm	25mm (AL/PVC)
Total Power	3.8KW	5.5KW	8.5KW
Overall Dimension	24005751560mm	36508251735mm	45007601620mm

✔

Core Advantages

Safety: Main machine overloading protection and thermal temperature control.
Design: Separated body design for easy movement into lifts or narrow workshops.
Efficiency: Automatic collection of bad products and auto-rewinding of strap material.
Maintenance: Module type design for easy sight, safe operation, and quick mould replacement.

?

Frequently Asked Questions

What materials can the AZ-05 blister machine handle?

The machine is designed to work with PVC, PTP, and paper-plastic materials, commonly used for hardware, medical, and cosmetic packaging.

Is the machine easy to operate for non-technical staff?

Yes, it features a user-friendly PLC touch screen interface in both English and Chinese, with automatic fault indication and maintenance guidance.

Can I adjust the blister size for different products?

Absolutely. The machine uses servo traction which allows the length of the blister traction to be adjusted within a specific range to fit different product dimensions.

What safety features are included?

It includes thermal temperature testing, main machine overload protection, material position testing, and an automatic stop function in case of failure.

Does the machine support batch number printing?

Yes, the machine can perform steel printing in up to 3 rows for batch numbers and production dates during the packaging process.

Is the equipment compliant with international standards?

Yes, the equipment is manufactured to meet CE, ISO, and SGS certification standards, ensuring high quality and safety.
